Серия ионисторов RG

Panasonic Industrial Europe GmbH

Общие характеристики

 Раздел Ионисторы
Рабочее напряжение

Документация на серию RG

Electric Double Layer Capacitors (Gold Capacitor) Stacked Coin Type Series : RG Features ● Endurance : +85 °C 2000 h be discharged mA current ● RoHS compliant ● Can Recommended applications ● Backup ● For of data/RTC of base station, electronic meter, and industrial equipment assist of rapid load change Specifications Category temp. range Maximum operating voltage Nominal capacitance Characteristics at low temperature Endurance Shelf life –25 °C to +85 °C 3.6 V.DC 0.22 F 1.0 F, 1.5 F Capacitance change ±30 % of initial measured value at +20 °C (at –25 °C) Internal resistance < 5 times of initial measured value at +20 °C (at –25 °C) After 2000 hours application of maximum operating voltage at +85 °C Capacitance change ±30 % of initial measured value at 20 °C 100 Ω or less (0.22 F) Internal resistance 40 Ω or less (1.0 F, 1.5 F) After 2000 hours storage at +85 °C without load (voltage) Capacitance change Capacitance change shall meet the specified limits for Endurance Internal resistance Internal resistance shall meet the specified limits for Endurance Dimensions in mm(not to scale) RG series 0.22(F) Terminal : V 11.5 max. 6.0 max. 3.0±0.5 0.2±0.05 5.0±0.8 1.0±0.1 – 5.0±0.5 1.0±0.1 0.2±0.05 3.0±0.5 20.0±0.5 0.8±0.05 (1.7) f19.0±0.3 20.5 Max. + 0.20±0.05 0.2±0.05 10.0±0.5 Sleeve 5.5±0.5 21.0 max. 4.0±0.3 11.5 max. 010.5 max. f19.0±0.3 Terminal : H 3.5±0.3 6.5 max. Sleeve 5.0 max. 10.5 max. 0.8±0.05 (1.7) Terminal : H 5.0±0.3 Terminal : V RG series 1.0, 1.5(F) (Unit : mm) Characteristics list Maximum operating voltage (V.DC) 3.6 0.22 0.176 to 0.396 < 50 1 or less EECRG0V224( ) 1.0 Min. packaging q'ty (pcs) 200 1.0 0.8 to 1.8 < 20 20 or less EECRG0V105( ) 4.1 100 1.5 1.2 to 2.7 < 20 20 or less EECRG0V155( ) 4.2 100 Capacitance (F) Capacitance Internal resistance Recommended tolerance (Initial specified value) discharge current (F) (Ω) at 1 kHz (mA) Parts number Mass (Reference value) (g) Do not use reflow soldering. (IR, Atmospherheating methods, etc.) Please refer to the page of “Application guidelines”. ( ) : Please use V or H to indicate terminal type. The recommended discharge current is a reference value. Please design your equipment(circuit) in consideration of IR dorop. Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use. Should a safety concern arise regarding this product, please be sure to contact us immediately. 02 Jan. 2016 PDF
Документация на EECRG0V105H

series catalog

Дата модификации: 19.03.2020

Размер: 213.3 Кб

6 стр.

Electric Double Layer Capacitors (Gold Capacitor) Stacked Coin Type Series : RG Low temperature assured product Features ● Endurance : +85 °C 2000 h temperature range : –40 °C to +85 °C ● RoHS compliant ● Category Recommended applications ● Backup of data/RTC of base station, electronic meter, and industrial equipment Specifications Category temp. range Maximum operating voltage Nominal capacitance Characteristics at low temperature Endurance Shelf life –40 °C to +85 °C 3.6 V.DC 0.22 F 1.0 F, 1.5 F Capacitance change ±30 % of initial measured value at +20 °C (at –40 °C) Internal resistance < 7 times of initial measured value at +20 °C (at –40 °C) After 2000 hours application of maximum operating voltage at +85 °C Capacitance change ±30 % of initial measured value at 20 °C 100 Ω or less (0.22 F) Internal resistance 40 Ω or less (1.0 F, 1.5 F) After 2000 hours storage at +85 °C without load (voltage) Capacitance change Capacitance change shall meet the specified limits for Endurance Internal resistance Internal resistance shall meet the specified limits for Endurance Dimensions in mm(not to scale) RG series (0.22 F) Terminal : V 3.0±0.5 11.5 max. 5.0±0.8 1.0±0.1 – 5.0±0.5 0.2±0.05 20.5 Max. 20.0±0.5 0.8±0.05 (1.7) f19.0±0.3 + 0.20±0.05 0.2±0.05 3.0±0.5 10.0±0.5 Sleeve 5.5±0.5 21.0 max. 4.0±0.3 0.2±0.05 6.0 max. 11.5 max. 010.5 max. f19.0±0.3 Terminal : H 3.5±0.3 6.5 max. Sleeve 5.0 max. 10.5 max. 0.8±0.05 (1.7) Terminal : H 5.0±0.3 Terminal : V RG series (1.0 F, 1.5 F) 1.0±0.1 (Unit : mm) Characteristics list Min. Category Maximum Internal Mass Capacitance operating Capacitance packaging temp. resistance Recommended ✽1 Parts number (Reference value) tolerance voltage q'ty range (F) (Initial specified value) discharge current (F) (g) (V.DC) (pcs) (°C) (Ω) at 1 kHz 0.22 0.176 to 0.396 300 µA or less EECRG0V224( )N 1.0 200 < 50 –40 to +85 3.6 1.0 0.8 to 1.8 < 20 1 mA or less EECRG0V105( )N 4.1 100 1.5 1.2 to 2.7 < 20 1 mA or less EECRG0V155( )N 4.2 100 ( ) : Please use V or H to indicate terminal type. ✽1 The recommended discharge current is a reference value. Please design your equipment(circuit) in consideration of IR drop. Do not use reflow soldering. Please refer to the page of “Application guidelines”. Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use. Should a safety concern arise regarding this product, please be sure to contact us immediately. 02 Aug. 2016 PDF
Документация на EECRG0V105H

N_GC_RG_N_E.indd

Дата модификации: 25.08.2016

Размер: 45.6 Кб

1 стр.

    Товары серии RG

    Наименование i Упаковка Ёмкость Траб
    EECRG0V105H (PAN)


    		 1 шт
    EECRG0V105V (PAN)

    		1 шт
    EECRG0V155V (PAN)


    		 1 шт — —
    EECRG0V224H (PAN)

    		1 шт
    EECRG0V224HN (PAN)


    		 1 шт
    EECRG0V224V (PAN)


    		 7 шт
    ELJRG15NJF (PAN)


    		 — —
