7010.9901.03

SCHURTER HOLDING AG (SCHURTER GROUP)
MKF Fuses https://www.schurter.com /PG01_2 Surface Mount Fuse, 7 x 2.54 mm, Quick-Acting F, 125 VAC, 125 VDC See below: UL 248-14 · 125 VAC · 125 VDC · Quick-Acting F Approvals and Compliances Description Applications - High breaking capacity - Directly solderable on printed circuit boards - Telecom - Household appliances References Round Solder Pads Type   172876 Weblinks pdf dat...
развернуть ▼ свернуть ▲


Технические характеристики

показать свернуть
Номинальный ток
Напряжение AC
Напряжение DC
Класс быстродействия
Тип монтажа
Отключающая способность AC
Особенности Board Mount (Cartridge Style Excluded)
Размер ø7×2.54 мм
Рабочая температура
Одобрение
Нашли ошибку? Выделите её курсором и нажмите CTRL + ENTER

Аналоги 14

показать свернуть
Тип Наименование Корпус Упаковка i Ток U AC U DC Класс Монтаж I dist. AC I dist. DC Особенности Примечания T раб Одобрение Карточка
товара
A- 0451.125MRL (LTL)

— в ленте 1000 шт Предохранитель плавкий - — Board Mount (Cartridge Style Excluded) FUSE BOARD MNT 125MA 125VAC/VDC
A- 0451.125NRL (LTL)

— 5000 шт Предохранитель плавкий - — Board Mount (Cartridge Style Excluded) FUSE BOARD MNT 125MA 125VAC/VDC
A- 0466.125NR (LTL)

SMD120632X16MM в ленте 5000 шт Предохранитель плавкий - Ток: 125 мА; U AC: 125 В; U DC: 125 В; Класс: Fast; Монтаж: 12... — Board Mount (Cartridge Style Excluded) FUSE BOARD MNT 125MA 125VAC/VDC
A- 0242.125UR (LTL)

— 500 шт FUSE 250V BARRIER FUSE SMT .125A —
A- 0459.125UR (LTL)

— в ленте 500 шт — Board Mount (Cartridge Style Excluded) FUSE BOARD MNT 125MA 125VAC/VDC
A- 0466.125NRHF (LTL)

SMD120632X16MM в ленте 5000 шт Предохранитель плавкий - Ток: 125 мА; U AC: 125 В; U DC: 125 В; Класс: Fast; Монтаж: 12... — Board Mount (Cartridge Style Excluded) FUSE BOARD MNT 125MA 125VAC/VDC
A- 0154.125DRL (LTL)

— 1500 шт Предохранитель плавкий - — — Board Mount (Cartridge Style Excluded) FUSE BOARD MNT 125MA 125VAC/VDC
A- 0448.125MR (LTL)

— 1000 шт Предохранитель плавкий - Ток: 125 мА; U AC: 125 В; U DC: 125 В; Класс: Fast; Монтаж: 2-... — Board Mount (Cartridge Style Excluded) FUSE BOARD MNT 125MA 125VAC/VDC
A- 0451.125MR (LTL)

— 1 шт Предохранитель плавкий - — Board Mount (Cartridge Style Excluded) FUSE BOARD MNT 125MA 125VAC/VDC
A- 0451.125MRSN (LTL)

— 1000 шт

 — — Board Mount (Cartridge Style Excluded) FUSE BOARD MNT 125MA 125VAC 2SMD
A- 0202.125HXG (LTL)

— 100 шт Предохранитель плавкий - Ток: 125 мА; U AC: 250 В; Класс: Fast; Монтаж: 2-SMD; Примечан... — — Board Mount (Cartridge Style Excluded) FUSE BOARD MNT 125MA 250VAC 2SMD
A- 3403.0157.11 (SCHURTER)

—

 — Board Mount (Cartridge Style Excluded) —
A- 3403.0157.24 (SCHURTER)

— 1 шт

 — Board Mount (Cartridge Style Excluded) —
A- 3404.0049.11 (SCHURTER)

—

 — Board Mount (Cartridge Style Excluded) —

Файлы 1

показать свернуть
MKF Fuses https://www.schurter.com /PG01_2 Surface Mount Fuse, 7 x 2.54 mm, Quick-Acting F, 125 VAC, 125 VDC See below: UL 248-14 · 125 VAC · 125 VDC · Quick-Acting F Approvals and Compliances Description Applications - High breaking capacity - Directly solderable on printed circuit boards - Telecom - Household appliances References Round Solder Pads Type   172876 Weblinks pdf data sheet, html datasheet, General Product Information, DistributorStock-Check, Detailed request for product Technical Data Rated Voltage Rated current Breaking Capacity Characteristic Mounting Admissible Ambient Air Temp. Climatic Category Material: Tube Material: Endcaps Unit Weight Storage Conditions Product Marking 63 - 125 VAC, 65 - 125 VDC 0.063 - 15 A 300 A Quick-Acting F PCB,SMT -55 °C to 85 °C 55/085/56 acc. to IEC 60068-1 Ceramics Copper alloy, tin-plated 0.15 g 0 °C to 60 °C, max. 70% r.h. , Rated current Soldering Methods Solderability Resistance to Soldering Heat Moisture Sensitivity Level Reflow, Wave Soldering Profile 235 °C / 2 sec acc. to IEC 60068-2-58, Test Td 260 °C / 10 sec acc. to IEC 60068-2-58, Test Td MSL 1, J-STD-020 Approvals and Compliances Detailed information on product approvals, code requirements, usage instructions and detailed test conditions can be looked up in Details about Approvals SCHURTER products are designed for use in industrial environments. They have approvals from independent testing bodies according to national and international standards. Products with specific characteristics and requirements such as required in the automotive sector according to IATF 16949, medical technology according to ISO 13485 or in the aerospace industry can be offered exclusively with customer-specific, individual agreements by SCHURTER. Approvals The approval mark is used by the testing authorities to certify compliance with the safety requirements placed on electronic products. Approval Reference Type: MKF Approval Logo Certificates Certification Body Description UL Approvals UL UL File Number: E42088 Design Standard Description Designed according to UL 248-14 Low voltage fuses - Part 14: Additional fuses Designed according to CSA22.2 No. 248.14 Low-Voltage Fuses - Part 14: Supplemental Fuses Product standards Product standards that are referenced Organization Circuit Protection 1 PDF
Документация на 7010.9901.03

MKF - Fuses Schurter AG, GS, PG01_2 Fuses, Datasheet, MKF

Дата модификации: 26.10.2021

Размер: 286.7 Кб

4 стр.

    Внимание! Точность указанного на сайте описания товара не может быть гарантирована. Для получения более полной и точной информации о товаре смотрите техническое описание (Datasheet) на сайте производителя.
