TDR 2-4812

TRACO
Baar, 11. December 2014 Cleaning Guideline Scope This guideline covers hermetically sealed board mounted Traco converters. We do not recommend washing insert moulded products, where it is difficult to get them dry inside. Please check also, if there is an additional comment about washing in the datasheet or application note of the concerned product. Note: We do generally not recommend washing...
развернуть ▼ свернуть ▲
Фотография серии TDR2SM

Технические характеристики

показать свернуть
Монтаж
Выходная мощность
Количество каналов
Входное напряжение
Параметры выходов
Возможности
Комплекс защит
Номинальное входное напряжение
Напряжение 1 выхода
Ток 1 выхода
Уровень пульсаций
КПД
Напряжение изоляции вход-выход
Размер 18.9×12.8×8.7 мм
Рабочая температура
Нашли ошибку? Выделите её курсором и нажмите CTRL + ENTER

Аналоги 23

показать свернуть
Тип Наименование Корпус Упаковка i Монтаж P вых Каналов U вх Выход Возможности Защита U вх ном. U1 U2 U3 I1 I2 I3 Шум КПД Паралл. сх. Uиз. вх-вых Uиз. вх-общ Uиз. вых-общ Uиз. вых-вых Серт. медиц. T раб Примечания Карточка
товара
A- MDD03F-12 (MW)

— 11 шт — — — — — — —
A- MDD03G-12 (MW)

— 11 шт — — — — — — —
A- WRA2412P-3WR2 (MORNSUN)

— в линейках 100 шт

 — — — — — — —
A- WRA2412S-3WR2 (MORNSUN)

SIP7 в линейках 6 шт — — — — — — —
A- WRA2412ZP-3WR2 (MORNSUN)

— в линейках 5 шт — — — — — — — — EN55024, light industry level, criteria A —
A- WRB2412P-3WR2 (MORNSUN)

— в линейках 20 шт

 — — — — — — — — — —
A- WRB2412S-3WR2 (MORNSUN)

SIP87 в линейках 100 шт — — — — — — — — —
A- WRB4812S-3WR2 (MORNSUN)

SIP87 1 шт — — — — — — — — —
A- TMR 2-2412WI (TRACO)

SIP87 в линейках 10 шт DC-DC модульный преобразователь - Монтаж: на плату, SIP9; P вых: 2 Вт; #: 1; U вх: 9...... — — — — — — — — — Защита от КЗ: продолжительная с автовосстановлением
A- TMR 2412 (TRACO)

SIP87 в линейках 10 шт — — — — — — — — — Защита от КЗ: продолжительная с автовосстановлением
A- TMR 2422 (TRACO)

SIP87 в линейках 10 шт DC-DC модульный преобразователь - Монтаж: на плату, SIP8; P вых: 2 Вт; #: 2; U вх: 18..... — — — — — — — Защита от КЗ: продолжительная с автовосстановлением
A- TMR 3-2412WI (TRACO)

SIP87 в линейках 10 шт — — — — — — — — — Защита от КЗ: продолжительная с автовосстановлением
A- TMR 3-2422WI (TRACO)

SIP87 в линейках 10 шт DC-DC модульный преобразователь - Монтаж: на плату, SIP8; P вых: 3 Вт; #: 2; U вх: 9...... — — — — — — — Защита от КЗ: продолжительная с автовосстановлением
A- TMR 3-4822 (TRACO)

SIP87 10 шт DC-DC модульный преобразователь - Монтаж: на плату, SIP8; P вых: 3 Вт; #: 2; U вх: 36..... — — — — — — — Защита от КЗ: продолжительная с автовосстановлением
A- TDN 3-4822WISM (TRACO)

SMD5 в линейках 10 шт — — — — — — — —
A- TEN 3-2412 (TRACO)

DIP-24 в линейках 10 шт DC-DC модульный преобразователь - Монтаж: на плату, DIP24; P вых: 3 Вт; #: 1; U вх: 18.... короткого замыкания, перенапряжения, перегрева — — — — — — — — — Защита от КЗ: продолжительная с автовосстановлением
A- TEN 3-2412WI (TRACO)

DIP-24 в линейках 10 шт DC-DC модульный преобразователь - Монтаж: на плату, DIP24; P вых: 3 Вт; #: 1; U вх: 9..... — — — — — — — Защита от КЗ: продолжительная с автовосстановлением
A- REC3-2412SRW/H/B (RECOM)

— в линейках 15 шт

 — — — — — — — — — —
A- RS3-2412S (RECOM)

SIP7 22 шт — — — — — — — — — —
A- SCWN03B-12 (MW)

DIP2410 в линейках 10 шт короткого замыкания, перегрузки, перенапряжения — — — — — — — —
A- SCWN03C-12 (MW)

DIP2410 короткого замыкания, перегрузки, перенапряжения — — — — — — — —
A- SPA02C-12 (MW)

SIP87 — — — — — — — —
A- SPAN02B-12 (MW)

— 1 шт — — — — — — — — —

Файлы 4

показать свернуть
Baar, 11. December 2014 Cleaning Guideline Scope This guideline covers hermetically sealed board mounted Traco converters. We do not recommend washing insert moulded products, where it is difficult to get them dry inside. Please check also, if there is an additional comment about washing in the datasheet or application note of the concerned product. Note: We do generally not recommend washing or cleaning electronic components. You should avoid it, if it is not absolutely necessary. It may reduce the reliability of the involved components in your application. Board cooling prior to cleaning process Converters and their associated application PCB assemblies should not be wash-cleaned after soldering until they had the opportunity to cool within the cleaning solution temperature. This will prevent vacuum absorption of the cleaning liquid into the module between the pins and the potting during cooling. Cleaning agents Cleaning method Classification Cleaning agents Water type Deionized water Ultrasonic wave Solvent type IPA Note: In general, the liquid temperature shall be less than 60°C. Cleaning process In aqueous cleaning, it is preferred to have an in-line cleaner system consisting of several cleaning stages (prewash, wash, rinse, final rinse, and drying). Deionised (DI) water is recommended for aqueous cleaning; the minimum resistively level is 1MΩ-cm. Tap-water quality varies per region in terms of hardness, chloride, and solid contents. Therefore, the use of tap water is not recommended for aqueous cleaning. Note: The total time of ultrasonic wave shall be less than 3 minutes. Drying After cleaning, assure that everything will be dry enough, that the moisture and other potential contaminants will not be present anymore. Use an air circulating chamber (e.g. 0.5-0.7m3/s) and thermal oven at 80-100°C (during 20-120min, depending on assembling, structure, components). Handheld air guns are not recommended. It is on customer’s own responsibility to ensure all components are dry. Product post-wash external appearance The marking or date-code may fade or disappear after cleaning. That does not concern the performance of the converter. Andreas Flühler, Head of Technical Services PDF
Рекомендации по промывке и сушке

Cleaning Guideline

Дата модификации: 02.02.2021

Размер: 79 Кб

1 стр.

DC/DC Converters TDR 2 Series, 2 Watt UL 60950-1 Features ◆ Compact design in SMD or DIP package ◆ Wide 2:1 input voltage range ◆ Fully regulated outputs ◆ Low ripple and noise ◆ No minimum load required ◆ Temperature range –40°C to +85°C without derating ◆ ◆ ◆ ◆ ◆ I/O isolation 1500 VDC Continuous short-circuit protection Remote On/Off control Fully RoHS compliant 3-year product warranty The TDR-2 series is a family of compact 2 W dc/dc-converters with 2:1 input voltage ranges and tightly regulated output voltages even under no load conditions. The product is available in SMD-package or in DIP-package. They work with high efficiency over the full load range and come with a remote On/Off input. The usability in temperature ranges of up to 85°C without power derating, continuous short circuit protection and excellent immunity against environmental influences make these converters very reliable. A TDR-2 converter is the ideal solution for space critical high end applications in communication equipment, instrumentation and industrial electronics. Models Order code DIP models TDR 2-0511 Order code SMD models TDR 2-0511SM TDR 2-0512 TDR 2-0512SM TDR 2-0513 TDR 2-0513SM TDR 2-0522 TDR 2-0522SM Input voltage range Output voltage 5.0 VDC 4.5 – 9.0 VDC (5 VDC nominal) 12 VDC Output current max. 400 mA 167 mA Efficiency typ. 80 % 81 % 15 VDC 134 mA 83 % ±12 VDC ±83 mA 81 % TDR 2-0523 TDR 2-0523SM ±15 VDC ±67 mA 82 % TDR 2-1211 TDR 2-1211SM 5.0 VDC 400 mA 81 % TDR 2-1212 TDR 2-1212SM 12 VDC 167 mA 81 % TDR 2-1213 TDR 2-1213SM TDR 2-1222 TDR 2-1222SM TDR 2-1223 9 – 18 VDC 15 VDC 134 mA 84 % ±12 VDC ±83 mA 83 % TDR 2-1223SM ±15 VDC ±67 mA 82 % (12 VDC nominal) TDR 2-2411 TDR 2-2411SM 5.0 VDC 400 mA 81 % TDR 2-2412 TDR 2-2412SM 12 VDC 167 mA 84 % TDR 2-2413 TDR 2-2413SM TDR 2-2422 TDR 2-2422SM TDR 2-2423 18 – 36 VDC 15 VDC 134 mA 84 % ±12 VDC ±83 mA 84 % TDR 2-2423SM ±15 VDC ±67 mA 84 % (24 VDC nominal) TDR 2-4811 TDR 2-4811SM 5.0 VDC 400 mA 81 % TDR 2-4812 TDR 2-4812SM 12 VDC 167 mA 82 % TDR 2-4813 TDR 2-4813SM 15 VDC 134 mA 82 % TDR 2-4822 TDR 2-4822SM TDR 2-4823 TDR 2-4823SM http://www.tracopower.com 36 – 75 VDC (48 VDC nominal) ±12 VDC ±83 mA 83 % ±15 VDC ±67 mA 83 % Page 1 of 4 PDF
Документация на серию TDR2SM

Datasheet

Дата модификации: 10.06.2013

Размер: 313.1 Кб

4 стр.

DC/DC Converters TDR 2WI Series, 2 Watt UL 60950-1 Features ◆ Compact design in SMD or DIP package ◆ Ultra wide 4:1 input voltage range ◆ Fully regulated outputs ◆ Low ripple and noise ◆ No minimum load required ◆ Temperature range –40°C to +85°C without derating ◆ ◆ ◆ ◆ ◆ I/O isolation 1500 VDC Continuous short-circuit protection Remote On/Off control Fully RoHS compliant 3-year product warranty The TDR-2WI series is a family of compact 2 W dc/dc-converters with 4:1 input voltage ranges and tightly regulated output voltages even under no load conditions. The product is available in SMD-package or in DIP-package. They work with high efficiency over the full load range and come with a remote On/Off input. The usability in temperature ranges of up to 85°C without power derating, continuous short circuit protection and excellent immunity against environmental influences make these converters very reliable. A TDR-2WI converter is the ideal solution for space critical high end applications in communication equipment, instrumentation and industrial electronics. Models Order code DIP models TDR 2-1211WI Order code SMD models TDR 2-1211WISM TDR 2-1212WI TDR 2-1212WISM TDR 2-1213WI TDR 2-1213WISM TDR 2-1222WI TDR 2-1222WISM TDR 2-1223WI Input voltage range Output voltage 5.0 VDC 4.5 – 18 VDC Output current max. 400 mA Efficiency typ. 79 % 12 VDC 167 mA 80 % 15 VDC 134 mA 81 % ±12 VDC ±83 mA 81 % TDR 2-1223WISM ±15 VDC ±67 mA 81 % TDR 2-2411WI TDR 2-2411WISM 5.0 VDC 400 mA 79 % TDR 2-2412WI TDR 2-2412WISM 12 VDC 167 mA 80 % TDR 2-2413WI TDR 2-2413WISM TDR 2-2422WI TDR 2-2422WISM TDR 2-2423WI (12 VDC nominal) 9 – 36 VDC 15 VDC 134 mA 82 % ±12 VDC ±83 mA 80 % TDR 2-2423WISM ±15 VDC ±67 mA 81 % TDR 2-4811WI TDR 2-4811WISM 5.0 VDC 400 mA 78 % TDR 2-4812WI TDR 2-4812WISM 12 VDC 167 mA 81 % TDR 2-4813WI TDR 2-4813WISM 15 VDC 134 mA 82 % TDR 2-4822WI TDR 2-4822WISM ±12 VDC ±83 mA 81 % TDR 2-4823WI TDR 2-4823WISM ±15 VDC ±67 mA 81 % http://www.tracopower.com (24 VDC nominal) 18 – 75 VDC (48 VDC nominal) Page 1 of 4 PDF
Документация на серию TDR2WI

Дата модификации: 21.12.2012

Размер: 400.7 Кб

4 стр.

DC/DC Converters TDR 2 Series, 2 Watt UL 60950-1 Features ◆ Compact design in SMD or DIP package ◆ Wide 2:1 input voltage range ◆ Fully regulated outputs ◆ Low ripple and noise ◆ No minimum load required ◆ Temperature range –40°C to +85°C without derating ◆ ◆ ◆ ◆ ◆ I/O isolation 1500 VDC Continuous short-circuit protection Remote On/Off control Fully RoHS compliant 3-year product warranty The TDR-2 series is a family of compact 2 W dc/dc-converters with 2:1 input voltage ranges and tightly regulated output voltages even under no load conditions. The product is available in SMD-package or in DIP-package. They work with high efficiency over the full load range and come with a remote On/Off input. The usability in temperature ranges of up to 85°C without power derating, continuous short circuit protection and excellent immunity against environmental influences make these converters very reliable. A TDR-2 converter is the ideal solution for space critical high end applications in communication equipment, instrumentation and industrial electronics. Models Order code DIP models TDR 2-0511 Order code SMD models TDR 2-0511SM TDR 2-0512 TDR 2-0512SM TDR 2-0513 TDR 2-0513SM TDR 2-0522 TDR 2-0522SM TDR 2-0523 TDR 2-1211 TDR 2-1212 TDR 2-1212SM TDR 2-1213 TDR 2-1213SM TDR 2-1222 TDR 2-1222SM TDR 2-1223 Input voltage range Output voltage 5.0 VDC 4.5 – 9.0 VDC Output current max. 400 mA Efficiency typ. 80 % 12 VDC 167 mA 81 % 15 VDC 134 mA 83 % ±12 VDC ±83 mA 81 % TDR 2-0523SM ±15 VDC ±67 mA 82 % TDR 2-1211SM 5.0 VDC 400 mA 81 % 12 VDC 167 mA 81 % (5 VDC nominal) 9 – 18 VDC 15 VDC 134 mA 84 % ±12 VDC ±83 mA 83 % TDR 2-1223SM ±15 VDC ±67 mA 82 % TDR 2-2411 TDR 2-2411SM 5.0 VDC 400 mA 81 % TDR 2-2412 TDR 2-2412SM 12 VDC 167 mA 84 % TDR 2-2413 TDR 2-2413SM TDR 2-2422 TDR 2-2422SM TDR 2-2423 (12 VDC nominal) 18 – 36 VDC 15 VDC 134 mA 84 % ±12 VDC ±83 mA 84 % TDR 2-2423SM ±15 VDC ±67 mA 84 % TDR 2-4811 TDR 2-4811SM 5.0 VDC 400 mA 81 % TDR 2-4812 TDR 2-4812SM 12 VDC 167 mA 82 % TDR 2-4813 TDR 2-4813SM 15 VDC 134 mA 82 % TDR 2-4822 TDR 2-4822SM ±12 VDC ±83 mA 83 % TDR 2-4823 TDR 2-4823SM ±15 VDC ±67 mA 83 % http://www.tracopower.com (24 VDC nominal) 36 – 75 VDC (48 VDC nominal) Page 1 of 4 PDF
Документация на серию TDR2SM

Дата модификации: 13.07.2012

Размер: 412.7 Кб

4 стр.

    Внимание! Точность указанного на сайте описания товара не может быть гарантирована. Для получения более полной и точной информации о товаре смотрите техническое описание (Datasheet) на сайте производителя.
