Серия Светодиод маломощный L-59EGW-CA

Общие характеристики

	Раздел	Светодиод маломощный
	Цвета свечения
	Количество цветов в корпусе
	Длина волны 1 цвета	625
	Длина волны 2 цвета	568
	Сила света 1 кристалла
	Сила света 2 кристалла
	Падение напряжения, тип.
	Угол по горизонтали
	Угол по вертикали
	Тип корпуса
	Тип линзы
	Схема включения
	Размер	5×5×8 мм
	Рабочая температура

Документация на серию L-59EGW-CA

L-59EGW-CA T-1 3/4 (5mm) Bi-Color Indicator Lamp DESCRIPTIONS PACKAGE DIMENSIONS The High Efficiency Red source color devices are made with Gallium Arsenide Phosphide on Gallium Phosphide Orange Light Emitting Diode The Green source color devices are made with Gallium Phosphide Green Light Emitting Diode FEATURES Uniform light output Low power consumption 3 leads with one common lead Long life-solid state reliability RoHS compliant Status indicator Illuminator Signage applications Decorative and entertainment lighting Commercial and residential architectural lighting g in K t h g i r b APPLICATIONS Notes: 1. All dimensions are in millimeters (inches). 2. Tolerance is ±0.25(0.01") unless otherwise noted. 3. Lead spacing is measured where the leads emerge from the package. 4. The specifications, characteristics and technical data described in the datasheet are subject to change without prior notice. SELECTION GUIDE Part Number Emitting Color (Material) Iv (mcd) @ 20mA [2] ■ High Efficiency Red (GaAsP/GaP) L-59EGW-CA Viewing Angle [1] Lens Type Min. Typ. 3 6 *1.2 *3 White Diffused ■ Green (GaP) 2θ1/2 60° 3 8 *3 *8 Notes: 1. θ1/2 is the angle from optical centerline where the luminous intensity is 1/2 of the optical peak value. 2. Luminous intensity / luminous flux: +/-15%. * Luminous intensity value is traceable to CIE127-2007 standards. © 2020 Kingbright. All Rights Reserved. Spec No: DSAA6306 / 1101005757 Rev No: V.22A Date: 03/27/2020 Page 1 / 5

Документация на L-59EGW-CA RG

L-59EGW-CA(Ver.22A)

Дата модификации: 27.03.2020

Размер: 1.07 Мб

5 стр.

T-1 3/4(5mm) BI-COLOR INDICATOR LAMP L-59EGW-CA Features ! UNIFORM ! LOW !3 Description LIGHT OUTPUT. The High Efficiency Red source color devices are made with POWER CONSUMPTION. ! MILKY Gallium Arsenide Phosphide on Gallium Phosphide Orange WHITE DIFFUSION LENS. LEADS WITH ONE COMMON LEAD. ! THIRD ! I.C. HIGH EFFICIENCY RED / GREEN COLOR (MIXED COLOR) AVAILABLE. Light Emitting Diode. The Green source color devices are made with Gallium Phosphide Green Light Emitting Diode. COMPATIBLE. ! LONG LIFE - SOLID STATE RELIABILITY . Package Dimensions Notes: 1. All dimensions are in millimeters (inches). 2. Tolerance is ±0.25(0.01") unless otherwise noted. 3. Lead spacing is measured where the lead emerge package. 4. Specifications are subject to change without notice. SPEC NO: DSAA6306 APPROVED: J.LU REV NO: V.3 CHECKED: Allen Liu DATE:JAN/06/2003 DRAWN: S.J.HOU PAGE: 1 OF 3

Документация на серию L-59EGW-CA

Дата модификации: 06.01.2003

Размер: 58.8 Кб

3 стр.

найти L-59EGW-CA.pdf

Товары серии L-59EGW-CA

Наименование	i	Упаковка
L-59EGW-CA RG (KGB)		500 шт
