Серия Светодиод маломощный L154A4

Kingbright

Общие характеристики

 Раздел Светодиод маломощный
Цвета свечения
Количество цветов в корпусе
Угол по горизонтали
Угол по вертикали
Размер 5×8.6 мм
Рабочая температура

Документация на серию L154A4

L-154A4SUREQBFZGEW T-1 3/4 (5mm) Full Color LED Lamp DESCRIPTIONS z z z z z z PACKAGE DIMENSIONS The Hyper Red source color devices are made with AlGaInP on GaAs substrate Light Emitting Diode The Blue source color devices are made with InGaN Light Emitting Diode The Green source color devices are made with InGaN Light Emitting Diode Electrostatic discharge and power surge could damage the LEDs It is recommended to use a wrist band or anti-electrostatic glove when handling the LEDs All devices, equipments and machineries must be electrically grounded FEATURES z z z z Uniform light output Low power consumption Long life-solid state reliability RoHS compliant APPLICATIONS z z z z z n i K Status indicator Illuminator Signage applications Decorative and entertainment lighting Commercial and residential architectural lighting ATTENTION b g g i r t h Blue Notes: 1. All dimensions are in millimeters (inches). 2. Tolerance is ±0.25(0.01") unless otherwise noted. 3. Lead spacing is measured where the leads emerge from the package. 4. The specifications, characteristics and technical data described in the datasheet are subject to change without prior notice. Observe precautions for handling electrostatic discharge sensitive devices SELECTION GUIDE Part Number Emitting Color (Material) Iv (mcd) @ 20mA [2] Lens Type ■ Hyper Red (AlGaInP) L-154A4SUREQBFZGEW ■ Blue (InGaN) White Diffused ■ Green (InGaN) Min. Typ. 400 1000 *120 *250 300 500 *300 *500 900 1700 *900 *1700 Viewing Angle [1] 2θ1/2 60° Notes: 1. θ1/2 is the angle from optical centerline where the luminous intensity is 1/2 of the optical peak value. 2. Luminous intensity / luminous flux: +/-15%. * Luminous intensity value is traceable to CIE127-2007 standards. © 2019 Kingbright. All Rights Reserved. Spec No: DSAJ9604 / 1101026761 Rev No: V.12A Date: 04/29/2019 Page 1 / 5 PDF
Документация на L-154A4SUREQBFZGEW

L-154A4SUREQBFZGEW(Ver.12A)

Дата модификации: 29.04.2019

Размер: 494.5 Кб

5 стр.

    Товары серии L154A4

    Наименование i Упаковка λ1 Iv1
    L-154A4SUREQBFZGEW (KGB)


    		 1 шт 640
    L-154A4SURKQBDZGW (KGB)

    		1 шт 650
