Серия мощных LED для освещения L7113

Общие характеристики

Документация на серию L7113

T-1 3/4 (5mm) SOLID STATE LAMP Part Number: L-7113PBC-A PRELIMINARY SPEC Blue ATTENTION OBSERVE PRECAUTIONS FOR HANDLING ELECTROSTATIC DISCHARGE SENSITIVE DEVICES Features Description z LOW POWER CONSUMPTION. The Blue source color devices are made with InGaN z POPULAR T-1 3/4 DIAMETER PACKAGE. on SiC Light Emitting Diode. z GENERAL PURPOSE LEADS. Static electricity and surge damage the LEDS. z RELIABLE AND RUGGED. It is recommended to use a wrist band or anti-electrostatic z LONG LIFE - SOLID STATE RELIABILITY. glove when handling the LEDs. z AVAILABLE ON TAPE AND REEL. All devices, equipment and machinery must be electrically z RoHS COMPLIANT. grounded. Package Dimensions Notes: 1. All dimensions are in millimeters (inches). 2. Tolerance is ±0.25(0.01") unless otherwise noted. 3. Lead spacing is measured where the leads emerge from the package. 4. Specifications are subject to change without notice. SPEC NO: DSAE4834 REV NO: V.10 APPROVED: WYNEC CHECKED: Allen Liu DATE: JUL/07/2007 DRAWN: Y.H.CHEN PAGE: 1 OF 5 ERP: 1101013155  PDF

Документация на L-7113PBC

L-7113PBC-A(Ver.10)

Дата модификации: 23.07.2007

Размер: 236.9 Кб

5 стр.

• найти L7113.pdf

Товары серии L7113

Наименование	i	Упаковка	Угол	Imax
L-7113PBC (KGB)
L-7113SECK-J3 (KGB)		500 шт	—	—
L-7113SF6C (KGB)		1000 шт	—	—
L-7113SF7BT (KGB)			—	—
L-7113SF7C (KGB)		1 шт	—	—
L-7113SRSGW (KGB)		500 шт	—	—
L-7113SYCK-J3 (KGB)			—	—
L7113HD (KGB)
L7113YT (KGB)
