EC4SAW-24S05HN

Cincon
EC4SAWH SERIES 6 WATT 4:1 INPUT ISOLATED DC-DC CONVERTER Features  Efficiency Up to 87.5%  Fixed Switching Frequency  Regulated Outputs  Negative Remote On/Off  3000Vdc I/O Isolation  Continuous Short Circuit Protection  Safety Meets IEC/EN/UL 62368-1  Shock & Vibration MIL-STD-810F Compliant OUTPUT CURRENT MODEL INPUT OUTPUT NUMBER VOLTAGE VOLTAGE MIN. MAX. 3.3 VDC 0 mA ...
развернуть ▼ свернуть ▲

  • Корпус: SIP8

Файлы 1

показать свернуть
EC4SAWH SERIES 6 WATT 4:1 INPUT ISOLATED DC-DC CONVERTER Features  Efficiency Up to 87.5%  Fixed Switching Frequency  Regulated Outputs  Negative Remote On/Off  3000Vdc I/O Isolation  Continuous Short Circuit Protection  Safety Meets IEC/EN/UL 62368-1  Shock & Vibration MIL-STD-810F Compliant OUTPUT CURRENT MODEL INPUT OUTPUT NUMBER VOLTAGE VOLTAGE MIN. MAX. 3.3 VDC 0 mA 1500 mA INPUT CURRENT % EFF. CAPACITOR FULL LOAD (3) (2) LOAD MAX. 4 mA 256 mA 81.5 80.5 4700 uF NO LOAD EC4SAW-24S33HN 9-36 VDC EC4SAW-24S05HN 9-36 VDC 5 VDC 0 mA 1200 mA 4 mA 292 mA 85.5 85.5 2200 uF EC4SAW-24S12HN 9-36 VDC 12 VDC 0 mA 500 mA 5 mA 291 mA 88 86 1100 uF EC4SAW-24S15HN 9-36 VDC 15 VDC 0 mA 400 mA 5 mA 286 mA 88 87.5 470 uF EC4SAW-24D05HN 9-36 VDC ±5 VDC 0 mA ±600 mA 4 mA 292 mA 85.5 85.5 1400 uF EC4SAW-24D12HN 9-36 VDC ±12 VDC 0 mA ±250 mA 6 mA 291 mA 88 86 660 uF EC4SAW-24D15HN 9-36 VDC ±15 VDC 0 mA ±200 mA 6 mA 289 mA 87 86.5 220 uF EC4SAW-48S33HN 18-74 VDC 3.3 VDC 0 mA 1500 mA 3 mA 127 mA 81 81 4700 uF EC4SAW-48S05HN 18-74 VDC 5 VDC 0 mA 1200 mA 3 mA 151 mA 84.5 83 2200 uF EC4SAW-48S12HN 18-74 VDC 12 VDC 0 mA 500 mA 3 mA 145 mA 88 86.5 1100 uF EC4SAW-48S15HN 18-74 VDC 15 VDC 0 mA 400 mA 3 mA 144 mA 88.5 87 470 uF EC4SAW-48D05HN 18-74 VDC ±5 VDC 0 mA ±600 mA 4 mA 149 mA 85 84 1400 uF EC4SAW-48D12HN 18-74 VDC ±12 VDC 0 mA ±250 mA 3 mA 144 mA 88 87 660 uF EC4SAW-48D15HN 18-74 VDC ±15 VDC 0 mA ±200 mA 3 mA 144 mA 88 87 220 uF NOTE: 1. Nominal Input Voltage 24 or 48VDC 2. Measured at Nominal Input Voltage 3. Measured at 12VDC for 24Vin, 24VDC for 48Vin PART NUMBER Series EC4SAW Nominal Input Voltage II Number of Outputs O Nominal Output Voltage XX Isolation Voltage Remote On/Off Logic L Y 33: 3.3VDC EC4SAW 24: 24 VDC 48: 48 VDC 05: 5.0VDC S: Single D: Dual 12: 12VDC H: 3000Vdc N: Negative 15: 15VDC Part Number Example: EC4SAW-24S12HN: 6W, 4:1 9-36Vdc Input, Single 12Vdc Output, 3000VDC Isolation, Negative Logic, www.cincon.com 1 REVISION: V10 PDF
Документация на EC4SAW-48S05HN

Datasheet-EC4SAWH It is the datasheet of EC4SAWH, 6Watts 4:1 Input Range SIP-8 Regulated DC-DC Converter

Дата модификации: 30.07.2021

Размер: 366.5 Кб

8 стр.
