APTB1612SURKCGKC-F01

Kingbright
APTB1612SURKCGKC-F01 1.6 x 1.25 mm Bi-Color SMD Chip LED Lamp DESCRIPTIONS      PACKAGE DIMENSIONS The Hyper Red source color devices are made with AlGaInP on GaAs substrate Light Emitting Diode The Green source color devices are made with AlGaInP on GaAs substrate Light Emitting Diode Electrostatic discharge and power surge could damage the LEDs It is recommended to use a wrist band...
развернуть ▼ свернуть ▲


Технические характеристики

показать свернуть
Цвета свечения
Количество цветов в корпусе
Длина волны 1 цвета 570
Длина волны 2 цвета 630
Сила света 1 кристалла
Сила света 2 кристалла
Падение напряжения, тип.
Угол по горизонтали
Угол по вертикали
Тип линзы
Схема включения
Размер 1.6×0.65 мм
Рабочая температура
Примечания Dual Color LED, Hyper Red/green, Water Clear, 1.2mm
Нашли ошибку? Выделите её курсором и нажмите CTRL + ENTER

Аналоги 2

показать свернуть
Тип Наименование Корпус Упаковка i Цвет N λ1 Длина волны 2 λ3 Iv1 Iv2 Iv3 Tц Поток U Pик αX αY CIE x CIE y Корпус Линза Схема T раб Примечания Карточка
товара
P= KPTB-1612SURKCGKC (KGB)

LED06051611METRIC в ленте 2000 шт LS: Светодиод 630 570 — — — — — — — — — — —
F~ APTB1612ESGC-F01 (KGB)

SMD4 в ленте 2000 шт

 568 617 — — — — — — — — — Dual Color LED, High Efficiency Red/super Bright Green, Water Clear, 1.25mm

Файлы 1

показать свернуть
APTB1612SURKCGKC-F01 1.6 x 1.25 mm Bi-Color SMD Chip LED Lamp DESCRIPTIONS      PACKAGE DIMENSIONS The Hyper Red source color devices are made with AlGaInP on GaAs substrate Light Emitting Diode The Green source color devices are made with AlGaInP on GaAs substrate Light Emitting Diode Electrostatic discharge and power surge could damage the LEDs It is recommended to use a wrist band or anti-electrostatic glove when handling the LEDs All devices, equipments and machineries must be electrically grounded Red FEATURES         1.6 mm x 1.25 mm SMD LED, 0.65 mm thickness Bi-color, low power consumption Wide viewing angle Ideal for backlight and indicator Package: 2000 pcs / reel Moisture sensitivity level: 3 Halogen-free RoHS compliant RECOMMENDED SOLDERING PATTERN APPLICATIONS      (units : mm; tolerance : ± 0.1) Backlight Status indicator Home and smart appliances Wearable and portable devices Healthcare applications ATTENTION Observe precautions for handling electrostatic discharge sensitive devices Notes: 1. All dimensions are in millimeters (inches). 2. Tolerance is ±0.2(0.008") unless otherwise noted. 3. The specifications, characteristics and technical data described in the datasheet are subject to change without prior notice. 4. The device has a single mounting surface. The device must be mounted according to the specifications. SELECTION GUIDE Part Number Emitting Color (Material) Iv (mcd) @ 20mA [2] ■ Hyper Red (AlGaInP) APTB1612SURKCGKC-F01 Min. Typ. 120 200 *40 *80 20 50 *20 *50 2θ1/2 150° Water Clear ■ Green (AlGaInP) Viewing Angle [1] Lens Type Notes: 1. θ1/2 is the angle from optical centerline where the luminous intensity is 1/2 of the optical peak value. 2. Luminous intensity / luminous flux: +/-15%. * Luminous intensity value is traceable to CIE127-2007 standards. © 2021 Kingbright. All Rights Reserved. Spec No: DSAH3786 / 1203002054 Rev No: V.13A Date: 01/07/2021 Page 1 / 4 PDF
Документация на APTB1612SURKCGKC-F01

APTB1612SURKCGKC-F01(Ver.13A)

Дата модификации: 07.01.2021

Размер: 551.2 Кб

4 стр.

    Внимание! Точность указанного на сайте описания товара не может быть гарантирована. Для получения более полной и точной информации о товаре смотрите техническое описание (Datasheet) на сайте производителя.
