MC3479

MC3479 3-Axis Accelerometer GENERAL DESCRIPTION FEATURES The MC3479 is a small form factor, integrated digital output 3-axis accelerometer with a feature set optimized for cell phones and consumer product motion sensing. Applications include user interface control, gaming motion input, electronic compass tilt compensation for cell phones, game controllers, remote controls and portable media p...
развернуть ▼ свернуть ▲

Технические характеристики

показать свернуть
Рабочие оси
Диапазон измерения
Выходной интерфейс
Напряжение питания
Ток потребления
Рабочая температура
  Примечания: 16-bit resolution; ODR = 0.5 - 1000 Гц; FIFO 32 ; Zero-g offset = 20/50 mg; 2x2x0.95 12pin LGA
Нашли ошибку? Выделите её курсором и нажмите CTRL + ENTER

Файлы 1

показать свернуть
MC3479 3-Axis Accelerometer GENERAL DESCRIPTION FEATURES The MC3479 is a small form factor, integrated digital output 3-axis accelerometer with a feature set optimized for cell phones and consumer product motion sensing. Applications include user interface control, gaming motion input, electronic compass tilt compensation for cell phones, game controllers, remote controls and portable media products. Range, Sampling & Power • • • • • • • • • • Low power consumption and small size are inherent in the monolithic fabrication approach, where the MEMS accelerometer is integrated in a single-chip with the electronics integrated circuit. • SPI, up to 10 MHz I2C interface, up to 1 MHz 2×2×0.92 mm 12-pin LGA package High reliability thru single-chip 3D silicon MEMS technology RoHS compliant Applications • • • • • • In the MC3479 the internal sample rate can be set from 0.5 to 2000 samples / second. The device supports the reading of sample and event status via polling or interrupts. Information furnished by MEMSIC is believed to be accurate and reliable. However, no responsibility is assumed by MEMSIC for its use, or for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of MEMSIC. ±2, ±4, ±8, ±12, ±16g range 16-bit single sample resolution 16-bit resolution with FIFO 0.5 to 2000 Hz Output Data Rate 4 μA typical Standby current Low typical active current Simple System Integration The MC3479 features a dedicated motion block which implements algorithms to support “any motion” and shake detection, tilt/flip and tilt 35 position detection. MEMSIC MC3479 APS-048-0072 v1.12 Final Datasheet Smartphone Wearable IoT & IoMT Remote controls, gaming Vibration in Cell phone VR & game controllers www.memsic.com Page 1 of 80 2021/05 PDF
Документация на серию MC3479

MC3479 Preliminary Datasheet

Дата модификации: 19.05.2022

Размер: 1.58 Мб

80 стр.
