MC3635

MC3635 3-Axis Accelerometer GENERAL DESCRIPTION The MC3635 is an ultra-low power, lownoise, integrated digital output 3-axis accelerometer with a feature set optimized for wearables and consumer product motion sensing. Applications include wearable consumer products, IoT devices, user interface control, gaming motion input, electronic compass tilt compensation for cell phones, game controller...
развернуть ▼ свернуть ▲


Технические характеристики

показать свернуть
Рабочие оси
Диапазон измерения
Выходной интерфейс
Напряжение питания
Ток потребления
Рабочая температура
Примечания 14-bit resolution; Zero-g offset = 40 mg; 1.6x1.6x0.94 10pin LGA;
Нашли ошибку? Выделите её курсором и нажмите CTRL + ENTER

Сопутствующие товары 1

показать свернуть
Наименование Корпус Упаковка Краткое описание Карточка
товара
EV3635B (MEMSIC)


Файлы 1

показать свернуть
MC3635 3-Axis Accelerometer GENERAL DESCRIPTION The MC3635 is an ultra-low power, lownoise, integrated digital output 3-axis accelerometer with a feature set optimized for wearables and consumer product motion sensing. Applications include wearable consumer products, IoT devices, user interface control, gaming motion input, electronic compass tilt compensation for cell phones, game controllers, remote controls and portable media products. Low noise and low power are inherent in the monolithic fabrication approach, where the MEMS accelerometer is integrated in a single-chip with the electronics integrated circuit. In the MC3635 the internal sample rate can be set from 14 to 1300 samples / second. Specific tap or sample acquisition conditions can trigger an interrupt to a remote MCU. Alternatively, the device supports the reading of sample and event status via polling. Information furnished by MEMSIC is believed to be accurate and reliable. However, no responsibility is assumed by MEMSIC for its use, or for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of MEMSIC. MEMSIC MC3635 APS-048-0044 v1.9 FEATURES Range, Sampling & Power      ±2, 4, 8, 12 or 16g ranges 8, 10 or 12-bit resolution with FIFO o 14-bit single samples Sample rate 14 - 1300 samples/sec o Sample trigger via internal oscillator, clock pin or software command Sniff and Wake modes o 0.3 μA Sniff current @ 1Hz o Separate or combined sniff/wake Ultra-Low Power with 32 sample FIFO o 0.9 μA typical current @ 25Hz o 1.6 μA typical current @ 50Hz o 2.8 μA typical current @ 100Hz o 36 μA typical current @ 1300Hz Simple System Integration       I2C interface, up to 1 MHz SPI Interface, up to 8 MHz 1.6 × 1.6 × 0.94 mm 10-pin package Single-chip 3D silicon MEMS Low noise to 2.3mgRMS ROHS Compliant www.memsic.com Page 1 of 85 2021/10 PDF
Документация на MC3635

MC3635 Datasheet

Дата модификации: 22.01.2023

Размер: 1.85 Мб

85 стр.

    Внимание! Точность указанного на сайте описания товара не может быть гарантирована. Для получения более полной и точной информации о товаре смотрите техническое описание (Datasheet) на сайте производителя.
