LS10-13B03SS-F

Mornsun
AC/DC Converter LS10-13BxxSS(-F) Series FEATURES 10W, DIY AC/DC converter  Ultra-wide 85 - 305VAC and 100 - 430VDC input voltage Range  Accepts AC or DC input (dual-use of same terminal)  Operating ambient temperature range -40℃ to +85℃       CB RoHS Multi-application available, flexible layout High power density, high reliability Low power consumption, green power Output short ci...
развернуть ▼ свернуть ▲
Внешний вид серии LS10-13BxxSS(-F)

Технические характеристики

показать свернуть
Выходная мощность (ном)
Выход
Напряжение 1 канала
Выходной ток 1 канала
Тип стабилизации
Вход
Конструктивное исполнение
Возможности
Типы защиты КЗ, перегрузка, перенапряжение
Количество выходов
Тип управления выходом
Исполнение
Входное напряжение AC
Входное напряжение DC
Коэффициент мощности
Напряжение изоляции вход-выход
Применение
КПД
Размер 44.5×22×15 мм
Рабочая температура
Примечание
Нашли ошибку? Выделите её курсором и нажмите CTRL + ENTER

Файлы 2

показать свернуть
AC/DC Converter LS10-13BxxSS(-F) Series FEATURES 10W, DIY AC/DC converter  Ultra-wide 85 - 305VAC and 100 - 430VDC input voltage Range  Accepts AC or DC input (dual-use of same terminal)  Operating ambient temperature range -40℃ to +85℃       CB RoHS Multi-application available, flexible layout High power density, high reliability Low power consumption, green power Output short circuit, over-current, over-voltage protection IEC/EN/UL62368 safety approval Designed to meet IEC/EN/UL60335 safety standards LS10-13BxxSS(-F) series is one of Mornsun’s highly efficient green power AC-DC Converter series. They feature ultra-wide wide input range accepting either AC or DC voltage, high efficiency, low power consumption and CLASS II reinforced insulation. All models are particularly suitable for industrial control, electric power, instrumentation and smart home applications which don’t have high requirement for dimension. A variety of EMC external circuits meet the needs of multiple industries. Selection Guide Nominal Output Voltage and Current (Vo/Io) 3.3V/2000mA Efficiency at 230VAC (%) Typ. 70 Capacitive Load (µF) Max. 1500 LS10-13B05SS(-F) 5V/2000mA 76 1500 LS10-13B09SS(-F) 9V/1100mA 78 1000 LS10-13B12SS(-F) 12V/830mA 80 680 LS10-13B15SS(-F) 15V/670mA 81 470 LS10-13B24SS(-F) 24V/420mA 82 330 Certification CE/UL/CB Part No. Output Power LS10-13B03SS(-F)* 6.6W 10W Note: ① *An “-F” suffix designates horizontal package vs. standard vertical mounting. ② If the product is used in a severe vibration application, it needs to be glued and fixed. Input Specifications Item Input Voltage Range Operating Conditions Min. Typ. Max. Unit AC input 85 -- 305 VAC DC input 100 -- 430 VDC 47 -- 63 Hz 115VAC -- -- 0.3 230VAC -- -- 0.15 115VAC -- 15 -- 230VAC -- 30 -- Input Frequency Input Current Inrush Current Recommended External Input Fuse A 1A, slow-blow, required Hot Plug Unavailable Output Specifications Item Operating Conditions Min. Typ. Max. Output Voltage Accuracy 0% - 100% load Line Regulation 3.3V output -- ±1.5 ±3 Other output -- ±1 ±2 Rated load -- ±0.5 ±1 Load Regulation 0% - 100% load -- ±1 ±1.5 Ripple & Noise* 20MHz bandwidth (peak-to-peak value) -- 80 150 mV ±0.02 -- %/°C -- Temperature Coefficient % Hiccup, continuous, self-recovery Short Circuit Protection ≥110%Io, self-recovery Over-current Protection Over-voltage Protection Unit 3VDC/5VDC Output ≤9VDC (Output voltage clamp or hiccup ) 9VDC Output ≤15VDC (Output voltage clamp or hiccup ) 12VDC/15VDC Output ≤25VDC (Output voltage clamp or hiccup ) 2019.11.01-A/2 Page 1 of 7 MORNSUN Guangzhou Science & Technology Co., Ltd. reserves the copyright and right of final interpretation PDF
Документация на LS10-13B24SS-F

LS10-13BxxSS(-F) Keywords:

Дата модификации: 01.11.2019

Размер: 1.47 Мб

7 стр.

AC/DC Converter LS10-13BxxSS(-F) Series FEATURES 10W, DIY AC/DC converter  Ultra-wide 85 - 305VAC and 100 - 430VDC input voltage Range  Accepts AC or DC input (dual-use of same terminal)  Operating ambient temperature range -40℃ ~ +85℃       CB RoHS Multi-application available, flexible layout High power density, high reliability Low power consumption, green power Output short circuit, over-current, over-voltage protection IEC/EN/UL62368 safety approval Designed to meet IEC/EN/UL60335 safety standards LS10-13BxxSS(-F) series is one of Mornsun’s highly efficient green power AC-DC Converter series. They feature ultra-wide wide input range accepting either AC or DC voltage, high efficiency, low power consumption and CLASS II reinforced insulation. All models are particularly suitable for industrial control, electric power, instrumentation and smart home applications which don’t have high requirement for dimension. A variety of EMC external circuits meet the needs of multiple industries. Selection Guide Nominal Output Voltage and Current (Vo/Io) 3.3V/2000mA Efficiency at 230VAC (%) Typ. 70 Capacitive Load (µF) Max. 1500 LS10-13B05SS(-F) 5V/2000mA 76 1500 LS10-13B09SS(-F) 9V/1100mA 78 1000 LS10-13B12SS(-F) 12V/830mA 80 680 LS10-13B15SS(-F) 15V/670mA 81 470 LS10-13B24SS(-F) 24V/420mA 82 330 Certification CE/UL/CB Part No. Output Power LS10-13B03SS(-F)* 6.6W 10W Note: ① *An “-F” suffix designates horizontal package vs. standard vertical mounting. ② If the product is used in a severe vibration application, it needs to be glued and fixed. Input Specifications Item Input Voltage Range Operating Conditions Min. Typ. Max. Unit AC input 85 -- 305 VAC DC input 100 -- 430 VDC 47 -- 63 Hz 115VAC -- -- 0.3 230VAC -- -- 0.15 115VAC -- 15 -- 230VAC -- 30 -- Input Frequency Input Current Inrush Current Recommended External Input Fuse A 1A, slow-blow, required Hot Plug Unavailable Output Specifications Item Operating Conditions Min. Typ. Max. Output Voltage Accuracy 0% - 100% load Line Regulation 3.3V output -- ±1.5 ±3 Other output -- ±1 ±2 Rated load -- ±0.5 ±1 Load Regulation 0% - 100% load -- ±1 ±1.5 Ripple & Noise* 20MHz bandwidth (peak-to-peak value) -- 80 150 mV ±0.02 -- %/°C -- Temperature Coefficient % Hiccup, continuous, self-recovery Short Circuit Protection ≥110%Io, self-recovery Over-current Protection Over-voltage Protection Unit 3VDC/5VDC Output ≤9VDC (Output voltage clamp or hiccup ) 9VDC Output ≤15VDC (Output voltage clamp or hiccup ) 12VDC/15VDC Output ≤25VDC (Output voltage clamp or hiccup ) 2019.08.26-A/1 Page 1 of 7 MORNSUN Guangzhou Science & Technology Co., Ltd. reserves the copyright and right of final interpretation PDF
Документация на серию LS10-13BxxSS(-F)

Subject:

Дата модификации: 26.08.2019

Размер: 1.47 Мб

7 стр.

    Внимание! Точность указанного на сайте описания товара не может быть гарантирована. Для получения более полной и точной информации о товаре смотрите техническое описание (Datasheet) на сайте производителя.
