URB2412YMD-40WR3

DC/DC Converter URB_YMD-40WR3 Series FEATURES 40W isolated DC-DC converter in 1x1 inch Ultra-wide input and regulated single output Patent Protection Ultra-Wide 4:1 input voltage range High efficiency up to 91.5% No-load power consumption as low as 0.096W I/O isolation test voltage 1.5k VDC Input under-voltage protection, output short-circuit, over-current, over–voltage, over-temperature pr...
развернуть ▼ свернуть ▲


Технические характеристики

показать свернуть
Монтаж
Выходная мощность
Количество каналов
Входное напряжение
Параметры выходов
Возможности
Комплекс защит КЗ, пониженное входное напряжение, перегрузка, перенапряжение
Номинальное входное напряжение
Напряжение 1 выхода
Напряжение изоляции вход-выход
Размер 25.4×25.4×11.7 мм
Рабочая температура
Нашли ошибку? Выделите её курсором и нажмите CTRL + ENTER

Аналоги 23

показать свернуть
Тип Наименование Корпус Упаковка i Монтаж P вых Каналов U вх Выход Возможности Защита U вх ном. U1 U2 U3 I1 I2 I3 Шум КПД Паралл. сх. Uиз. вх-вых Uиз. вх-общ Uиз. вых-общ Uиз. вых-вых Серт. медиц. T раб Примечания Карточка
товара
A- URB2412LD-50WR3 (MORNSUN) 1 шт

DC-DC Regulated Power Supply Module, 1 Output, 50W, Hybrid INPUT UNDERVOLTAGE; OUTPUT SHORT CIRCUIT; OVER VOLTAGE; OVER CURRENT
A- URB2412LD-60WHR3 (MORNSUN)

КЗ, пониженное входное напряжение, перегрузка, перенапряжение
A- URB2412LD-60WR3 (MORNSUN)

КЗ, пониженное входное напряжение, перегрузка, перенапряжение
A- RP40Q-11012SRUW/N (RECOM)

DC-DC Regulated Power Supply Module, 1 Output, 40W, Hybrid OVER CURRENT; OVER VOLTAGE; OVERLOAD; THERMAL: SHORT CIRCUIT
A- RPMB12-3.0-EVM-1 (RECOM)
A- 2320018 (PHOENIX)
2320018 MINI-PS- 12- 24DC/ 5-15DC/2 (PHOENIX)
1 шт

DC-DC Regulated Power Supply Module, 1 Output, 60W, Hybrid
A- VI-J11-CY (VIC)

DC-DC Regulated Power Supply Module, 1 Output, 50W, Hybrid
A- V48SR12005NRFA (DELTA)

DC-DC Regulated Power Supply Module, 1 Output, 66W, Hybrid
A- DTE6048S12 (XP POWER)

DC-DC Regulated Power Supply Module, 1 Output, 60W, Hybrid
A- JWL4024S12 (XP POWER)

DC-DC Regulated Power Supply Module, 1 Output, 39.96W, Hybrid
A- JWL4048D12 (XP POWER)

DC-DC Regulated Power Supply Module, 2 Output, 40W, Hybrid ±
A- JWL5024S12 (XP POWER)

DC-DC Regulated Power Supply Module, 1 Output, 50W, Hybrid
A- JWL5048S12 (XP POWER)

DC-DC Regulated Power Supply Module, 1 Output, 50W, Hybrid
A- CQE50W-24S12 (CINCON) CASE SCW/DCW08

DC-DC Regulated Power Supply Module, 1 Output, 49.92W, Hybrid OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE; THERMAL
A- UEI-12/5-Q48N-C (MURATAPS) 2X1INCH 1 шт

DC-DC Regulated Power Supply Module, 1 Output, 60W, Hybrid
A- CQE50W-48S12 (CINCON) CASE SCW/DCW08

DC-DC Regulated Power Supply Module, 1 Output, 49.92W, Hybrid OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE; THERMAL
A- ECLB60W-24D12 (CINCON)

DC-DC Regulated Power Supply Module, 2 Output, 60W, Hybrid OVER CURRENT, OVER VOLTAGE, SHORT CIRCUIT PROTECTION
A- ECLB60W-24S12 (CINCON)

DC-DC Regulated Power Supply Module, 1 Output, 60W, Hybrid OVER CURRENT, OVER VOLTAGE, SHORT CIRCUIT PROTECTION
A- ECLB60W-48D12 (CINCON)

DC-DC Regulated Power Supply Module, 2 Output, 60W, Hybrid OVER CURRENT, OVER VOLTAGE, SHORT CIRCUIT PROTECTION
A- ECLB60W-48S12 (CINCON)

DC-DC Regulated Power Supply Module, 1 Output, 60W, Hybrid OVER CURRENT, OVER VOLTAGE, SHORT CIRCUIT PROTECTION
A- CHB50-48S12 (CINCON)

DC-DC Regulated Power Supply Module, 1 Output, 50W, Hybrid OUTPUT OVER VOLTAGE; SHORT CIRCUIT
A- ULS-12/5-D48N-C (MURATAPS) 1 шт

DC-DC Regulated Power Supply Module, 1 Output, 60W, Hybrid
A- VI-JW1-CY (VIC)

DC-DC Regulated Power Supply Module, 1 Output, 50W, Hybrid

Файлы 1

показать свернуть
DC/DC Converter URB_YMD-40WR3 Series FEATURES 40W isolated DC-DC converter in 1x1 inch Ultra-wide input and regulated single output Patent Protection Ultra-Wide 4:1 input voltage range High efficiency up to 91.5% No-load power consumption as low as 0.096W I/O isolation test voltage 1.5k VDC Input under-voltage protection, output short-circuit, over-current, over–voltage, over-temperature protection  Operating ambient temperature range: -40℃ to +105℃  Industry standard pin-out  Meets EN62368 approval standard      RoHS URB_YMD-40WR3 series of isolated 40W DC-DC converter products with an ultra-wide 4:1 input voltage range. They feature efficiencies up to 91%, input to output isolation is tested with 1500VDC and the converter safety operate ambient temperature of -40℃ to +105℃, input under-voltage protection, output short-circuit, over-current, over-voltage and over-temperature protection. They are ideally and widely used in applications such as industrial control, electric power, instruments and communications. Selection Guide Voltage (VDC) Current(mA) Max./Min. Full Load ② Efficiency (%) Min./Typ. URB2403YMD-40WR3 3.3 10000/0 87/89.5 7200 URB2405YMD-40WR3 5 8000/0 88/90 7200 12 3333/0 89/91.2 2000 15 2667/0 89/91.5 1500 URB2424YMD-40WR3 24 1667/0 88/90.1 1000 URB2428YMD-40WR3 28 1429/0 88/90.1 1000 Input Voltage (VDC) Certification -- Part No. URB2412YMD-40WR3 URB2415YMD-40WR3 Nominal (Range) ① Max. 24 (9-36) 40 Output Capacitive Load (µF)Max. Notes: 1 Exceeding the maximum input voltage may cause permanent damage; 2 Efficiency is measured in nominal input voltage and rated output load; 3 Rated output load is derated to 75% at minimun input voltage. Input Specifications Item Input Current (full load / no-load) Operating Conditions Nominal input voltage Min. Typ. Max. 3.3V output -- 1545/4 1580/12 Others -- 1852/4 1894/12 -- 100 -- -0.7 -- 50 -- -- 9 5.5 7.5 -- -- 30 100 Reflected Ripple Current Surge Voltage (1sec. max.) Start-up Voltage Nominal input voltage Input under-voltage protection Start-up Time Nominal input voltage & constant resistance load Input Filter mA VDC ms Capacitance filter Unavailable Hot Plug Module on Ctrl* Unit Ctrl pin open or pulled high (TTL 3.5-12VDC) Module off Input current when off Ctrl pin pulled low to GND (0-1.2VDC) -- 6 12 mA Note: *The Ctrl pin voltage is referenced to input GND. 2022.5.18-A/0 Page 1 of 6 MORNSUN Guangzhou Science & Technology Co., Ltd. reserves the copyright and right of final interpretation PDF
Документация на серию URB_YMD-40WR3

URB_YMD-40WR3 Series Keywords:

Дата модификации: 08.06.2022

Размер: 1.84 Мб

6 стр.
