Технические характеристики

показать свернуть
Тип преобразователя
Мощность выходная
Диапазон выходных напряжений
Диапазон выходных токов
Напряжение сети/входное номинальное
Режим стабилизации
Тип диммирования
Исполнение конструктивное
Степень защиты (IP)
Подстройка выходных параметров
Диапазон входных напряжений (AC)
Диапазон входных напряжений (DC)
Напряжение изоляции вход-выход
Количество выходов
Коэффициент мощности
Функция защиты КЗ, перегрузка, перенапряжение, перегрев
Температура рабочая
Размер 252×90×43.8 мм
Применение для архитектурной подсветки и COB-матриц
Особенности низкие пульсации, гарантия 7 лет
Нашли ошибку? Выделите её курсором и нажмите CTRL + ENTER

Файлы 2

показать свернуть
HLG-320H 320W Constant Voltage + Constant Current LED Driver F 110 M M SELV IP65 IP67 ■ Features Constant Voltage + Constant Current mode output Metal housing with class I design Built-in active PFC function IP67 / IP65 rating for indoor or outdoor installations •Function options: output adjustable via potentiometer; 3 in 1 dimming Typical lifetime > 62000 hours 7 years warranty series Bauar t gepruft Sicherheit egel ma ge od o s be wac g www. tuv.com ID 2000000000 Type HL ■ Applications LED street lighting  LED high-bay lighting Parking space lighting  LED fishing lamp  LED greenhouse lighting Type “HL” for use in ClassⅠ, Division 2 hazardous (Classified) location. ■ Description HLG-320H series is a 320W AC/DC LED driver featuring the dual mode constant voltage and constant current output. HLG-320H operates from 90~305VAC and offers models with different rated voltage ranging between 12V and 54V. Thanks to the high efficiency up to 94%, with the fanless design, the entire series is able to operate for -40 ℃ ~ +90 ℃ case temperature under free air convection. The design of metal housing and IP67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications. HLG-320H is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system. ■ Model Encoding HLG - 320H - 15 A Function options Rated output voltage (12V/15V/20V/24V/30V/36V/42V/48V/54V) Rated wattage Series name Type Blank A B IP Level IP67 IP65 IP67 C ------ D IP67 Function Io and Vo fixed Io and Vo adjustable through built-in potentiometer 3 in 1 dimming function (1~10VDC, 10V PWM signal and resistance) Terminal block for I/O connection. Output voltage and constant current level can be adjusted through internal potentiometer. Timer dimming function, contact MEAN WELL for details(safety pending). Note In Stock In Stock In Stock By request By request File Name:HLG-320H-SPEC 2016-10-25 PDF
Документация на HLG-320H-48


Дата модификации: 25.10.2016

Размер: 218.9 Кб

10 стр.

HLG-320H 320W Single Output Switching Power Supply E¡¡E¡½ ¡E ¡E¡E ¡E¡E ¡E¡E ¡E¡E E¡ series Features : Universal AC input / Full range (up to 305VAC) Built-in active PFC function High efficiency up to 95% Protections: Short circuit / Over current / Over voltage / Over temperature Cooling by free air convection OCP point adjustable through output cable or internal potentiometer IP67 / IP65 design for indoor or outdoor installations Three in one dimming function (1~10Vdc or PWM signal or resistance) Suitable for LED lighting and street lighting applications Compliance to worldwide safety regulations for lighting Suitable for dry / damp / wet location 5 years warranty (Note.10) 110 F HLG-320H-12 A M M IP65 IP67 SELV Blank : IP67 rated. Cable for I/O connection. A : IP65 rated. Output voltage and constant current level can be adjusted through internal potentiometer. B : IP67 rated. Constant current level adjustable through output cable with 1~10Vdc or PWM signal or resistance. C : Terminal block for I/O connection. Output voltage and constant current level can be adjusted through internal potentiometer. D (option) : IP67 rated. Timer dimming function, contact MEAN WELL for details. SPECIFICATION MODEL DC VOLTAGE HLG-320H-12 HLG-320H-15 HLG-320H-20 HLG-320H-24 HLG-320H-30 HLG-320H-36 HLG-320H-42 HLG-320H-48 HLG-320H-54 12V 15V 20V 24V 30V 36V 42V 48V 54V 7.5 ~ 15V 10 ~ 20V 12 ~ 24V 18 ~ 36V 21 ~ 42V 24 ~ 48V 27 ~ 54V 8.9A 7.65A 6.7A 5.95A CONSTANT CURRENT REGION Note.4 6 ~12V RATED CURRENT 22A 19A 15A 13.34A 15 ~ 30V 10.7A RATED POWER 264W 285W 300W 320.16W 321W 320.4W 321.3W 321.6W 321.3W 150mVp-p 150mVp-p 150mVp-p 200mVp-p 250mVp-p 250mVp-p 250mVp-p 350mVp-p 17 ~ 22V 21 ~ 26V 26 ~ 32V 32 ~ 39V 38 ~ 45V 43 ~ 52V 49 ~ 58V 3.8 ~ 7.65A ¡Ó1.0% Ó¡ 0.5% Ó¡ 0.5% 3.35 ~ 6.7A ¡Ó1.0% Ó¡ 0.5% Ó¡ 0.5% RIPPLE & NOISE (max.) Note.2 150mVp-p VOLTAGE ADJ. RANGE Note.6 10.8 ~ 13.5V 13.5 ~ 17V OUTPUT Can be adjusted by internal potentiometer A type only CURRENT ADJ. RANGE 11 ~ 22A VOLTAGE TOLERANCE Note.3 LINE REGULATION LOAD REGULATION SETUP, RISE TIME INPUT 15ms at full load Note.5 90 ~ 305VAC ¡Ó1.0% Ó¡ 0.5% Ó¡ 0.5% 2.97 ~ 5.95A 230VAC /115VAC 230VAC /115VAC 127 ~ 431VDC PF>0.98/115VAC, PF>0.95/230VAC, PF>0.94/277VAC at full load (Please refer to "Power Factor Characteristic" curve) 91% 92.5% 93.5% EFFICIENCY (Typ.) (277Vac) 91.5% 93% 94% AC CURRENT (Typ.) INRUSH CURRENT(Typ.) 3.5A / 115VAC 1.65A / 230VAC COLD START 75A/230VAC 94% 94% 94.5% 94.5% 1.45A / 277VAC 94.5% 95% 95% 95% 95% 95% 95% 95% 53.5 ~ 60V 59 ~ 65V <0.75mA / 277VAC Note.4 OVER VOLTAGE 95 ~ 108% Protection type : Constant current limiting, recovers automatically after fault condition is removed Hiccup mode, recovers automatically after fault condition is removed. 33 ~ 37V 14 ~ 17V 17.5 ~ 21V 22.5 ~ 27V 27 ~ 33V 40 ~ 46V ¢J ¡Ó ¢J 100 10 (RTH2) Protection type : Shut down and latch off o/p voltage, re-power on to recover WORKING TEMP. -40 ~ +70 SAFETY STANDARDS Note.7 46.5 ~ 53V Protection type : Shut down and latch off o/p voltage, re-power on to recover OVER TEMPERATURE VIBRATION ¢J (Refer to "Derating Curve") 20 ~ 95% RH non-condensing -40 ~ +80¢J, 10 ~ 95% RH ¡Ó0.03%/¢J (0 ~ 50¢J) 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes UL8750, CSA C22.2 No. 250.0-08, EN61347-1, EN61347-2-13 independent (except for HLG-320H C type),IP65 or IP67, J61347-1, J61347-2-13 approved ; design refer to UL60950-1, TUV EN60950-1 WITHSTAND VOLTAGE I/P-O/P:3.75KVAC ISOLATION RESISTANCE I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH Compliance to EN55015, EN55022 (CISPR22) Class B, EN61000-3-2 Class C ( 50% load) ; EN61000-3-3 EMC EMISSION EMC IMMUNITY MTBF DIMENSION PACKING NOTE ¡Ó Ó¡ 0.5% Ó¡ 0.5% EFFICIENCY (Typ.) (230Vac) WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY TEMP. COEFFICIENT OTHERS ¡Ó Ó¡ 0.5% Ó¡ 0.5% POWER FACTOR (Typ.) SHORT CIRCUIT EMC ¡Ó Ó¡ 0.5% Ó¡ 0.5% 47 ~ 63Hz OVER CURRENT SAFETY & 6.67 ~ 13.34A 5.35 ~ 10.7A 4.45 ~ 8.9A 1.0% 1.0% 1.0% 7.5 ~ 15A ¡Ó1.5% Ó¡ 0.5% Ó¡ 1.0% FREQUENCY RANGE LEAKAGE CURRENT PROTECTION ¡Ó2.0% Ó¡ 0.5% Ó¡ 1.5% Note.8 2500ms, 80ms at full load HOLD UP TIME (Typ.) VOLTAGE RANGE 9.5 ~ 19A ¡Ó3.0% Ó¡ 0.5% Ó¡ 2.0% I/P-FG:2KVAC O/P-FG:0.5KVAC ¢J ¡Ù Compliance to EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024, light industry level (surge 4KV), criteria B 157.1K hrs min. MIL-HDBK-217F (25 ) 252*90*43.8mm (L*W*H) 1.88Kg; 8pcs/16Kg/0.92CUFT ¢J ¢J 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation. 4. Constant current operation region is within 50% ~100% rated output voltage. This is the suitable operation region for LED related applications, but please reconfirm special electrical requirements for some specific system design. 5. Derating may be needed under low input voltages. Please check the static characteristics for more details. 6. Type A and type C only. 7. Safety and EMC design refer to EN60598-1, subject CNS15233, GB7000.1, FCC part18. 8. Length of set up time is measured at cold first start. Turning ON/OFF the power supply may lead to increase of the set up time. 9. The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again. 10. Refer to warranty statement. PDF
Документация на серию HLG-320H

HLG-320H.cdr Keywords:

Дата модификации: 18.09.2012

Размер: 324.1 Кб

7 стр.

    Внимание! Точность указанного на сайте описания товара не может быть гарантирована. Для получения более полной и точной информации о товаре смотрите техническое описание (Datasheet) на сайте производителя.
