Технические характеристики

показать свернуть
Тип преобразователя
Мощность выходная
Диапазон выходных напряжений
Диапазон выходных токов
Напряжение сети/входное номинальное
Режим стабилизации
Тип диммирования
Исполнение конструктивное
Степень защиты (IP)
Подстройка выходных параметров
Диапазон входных напряжений (AC)
Диапазон входных напряжений (DC)
Напряжение изоляции вход-выход
Количество выходов
Коэффициент мощности
Функция защиты КЗ, перегрузка, перенапряжение, перегрев
Температура рабочая
Размер 162×43×32 мм
Нашли ошибку? Выделите её курсором и нажмите CTRL + ENTER

Аналоги 1

показать свернуть
Тип Наименование Корпус Упаковка i Тип преобразователя Мощность выходная Напряжение выходное Ток выходной Напряжение входное Режим стабилизации Димминг Исполнение конструктивное Степень защиты (IP) Тип управления выходом Напряжение входное (AC) Напряжение входное (DC) Напряжение изоляции Количество выходов Коэффициент мощности Эффективность Функция защиты Температура рабочая Применение Особенности Карточка
F~ LPF-60-48 (MW)
в коробках 32 шт AC-DC сетевой преобразователь - P вых: 60 Вт; Выход: 48 В; U1: 28.8...48 В; I1: 1.25 А;... КЗ, перегрузка, перенапряжение, перегрев

Файлы 2

показать свернуть
LPF-40 40W Single Output Switching Power Supply series ■ Features : •Universal AC input / Full range (up to 305VAC) •Built-in active PFC function •High efficiency up to 89% •Protections: Short circuit / Over current / Over voltage / Over temperature •Cooling by free air convection •Fully isolated plastic case •Fully encapsulated with IP67 level (Note.6) •Class Ⅱ power unit, no FG •Class 2 power unit •Suitable for LED lighting and moving sign applications •Compliance to worldwide safety regulations for lighting •Suitable for dry / damp / wet locations •5 years warranty F 110 M M SELV IP67 ( for 48V,54V only) ( except for 48V,54V ) SPECIFICATION MODEL DC VOLTAGE LPF-40-12 LPF-40-15 LPF-40-20 LPF-40-24 LPF-40-30 LPF-40-36 LPF-40-42 LPF-40-48 LPF-40-54 12V 15V 20V 24V 30V 36V 42V 48V 54V 9 ~ 15V 12 ~ 20V 14.4 ~ 24V 21.6 ~ 36V 25.2 ~ 42V 28.8 ~ 48V 32.4 ~ 54V 1.12A 0.96A 0.84A 0.76A CONSTANT CURRENT REGION Note.4 7.2 ~12V OUTPUT RATED CURRENT 3.34A 2.67A 2A 1.67A 18 ~ 30V 1.34A RATED POWER 40.08W 40.08W 40W 40.08W 40.2W 40.32W 40.32W 40.32W 41.04W RIPPLE & NOISE (max.) Note.2 150mVp-p 150mVp-p 150mVp-p 150mVp-p 200mVp-p 250mVp-p 250mVp-p 250mVp-p 350mVp-p VOLTAGE TOLERANCE Note.3 ±4.0% ±4.0% ±4.0% ±4.0% ±4.0% ±4.0% ±4.0% ±4.0% ±4.0% LINE REGULATION ±0.5% ±0.5% ±0.5% ±0.5% ±0.5% ±0.5% ±0.5% ±0.5% ±0.5% LOAD REGULATION ±2.0% ±1.5% ±1.0% ±0.5% ±0.5% ±0.5% ±0.5% ±0.5% ±0.5% SETUP, RISE TIME Note.7 1000ms, 80ms / 115VAC at full load HOLD UP TIME (Typ.) VOLTAGE RANGE INPUT 16ms/230VAC Note.5 90 ~ 305VAC 16ms/115VAC at full load 127 ~ 431VDC FREQUENCY RANGE 47 ~ 63Hz POWER FACTOR (Typ.) PF>0.97/115VAC, PF>0.95/230VAC, PF>0.92/277VAC at full load (Please refer to "Power Factor Characteristic" curve) EFFICIENCY (Typ.) 84% 86% 88% 85% 87% 0.6A / 115VAC 0.3A / 230VAC 0.25A / 277VAC COLD START 50A(twidth=210μs measured at 50% Ipeak) at 230VAC AC CURRENT (Typ.) INRUSH CURRENT (Typ.) LEAKAGE CURRENT OVER CURRENT PROTECTION 1200ms, 80ms / 230VAC 88% 90% 90% 54 ~ 63V 59 ~ 66V <0.75mA / 240VAC Note.4 SHORT CIRCUIT OVER VOLTAGE 95 ~ 108% Protection type : Constant current limiting, recovers automatically after fault condition is removed Hiccup mode, recovers automatically after fault condition is removed. 34 ~ 40V 15 ~ 17V 17.5 ~ 21V 23 ~ 27V 28 ~ 35V Shut down o/p voltage, re-power on to recover WORKING TEMP. -40 ~ +70℃ (Refer to "Derating Curve") WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY TEMP. COEFFICIENT VIBRATION SAFETY STANDARDS Note.6 41 ~ 49V 20 ~ 95% RH non-condensing -40 ~ +80℃, 10 ~ 95% RH ±0.03%/℃ (0 ~ 50℃) 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes UL8750, CSA C22.2 No. 250.0-08(except for 48V, 54V), EN61347-1, EN61347-2-13 independent, IP67, J61347-1, J61347-2-13 approved ; design refer to UL60950-1, TUV EN60950-1 SAFETY & WITHSTAND VOLTAGE I/P-O/P:3.75KVAC EMC I/P-O/P:100M Ohms / 500VDC / 25℃/ 70% RH Compliance to EN55015, EN61000-3-2 Class C (≧60% load) ; EN61000-3-3 ISOLATION RESISTANCE 46 ~ 54V Protection type : Shut down and latch off o/p voltage, re-power on to recover OVER TEMPERATURE EMC EMISSION 88.5% Compliance to EN61000-4-2,3,4,5,6,8,11; EN61547, EN55024, light industry level(surge 2KV), criteria A 438.8K hrs min. MIL-HDBK-217F (25℃) 162.5*43*32mm (L*W*H) DIMENSION 0.44Kg; 32pcs/15.08Kg/0.93CUFT PACKING 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature. EMC IMMUNITY MTBF OTHERS NOTE 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation. 4. Please refer to "DRIVING METHODS OF LED MODULE". 5. Derating may be needed under low input voltages. Please check the static characteristics for more details. 6. Suitable for indoor use or outdoor use without direct sunlight exposure. Please avoid immerse in the water over 30 minutes. 7. Length of set up time is measured at cold first start. Turning ON/OFF the power supply may lead to increase of the set up time. 8. The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again. File Name:LPF-40-SPEC 2013-11-27 PDF
Документация на серию LPF-40


Дата модификации: 18.12.2013

Размер: 103.7 Кб

3 стр.
